Turcomdecor is a representative company in Türkiye and neighboring countries, of world renown production lines, technical equipment, chemicals and spare parts in wood based panel, chemical and food sectors.
Turnkey solutions in the woodpanel production industry starting from process and plant design stage. Initial machinery set-up and personnel training together with the supplier’s expert technical team.
20+ years of hands-on experience in double-belt continuous and short cycle isobaric presses used in the forestry products industry. Swift response periods in technical services, minimizing production downtime for our clients.
Countless examples of margin improvement initiatives in the forestry industry. 3-phase cost reduction program aiming at production excellency includes a diagnostic inspection of current production processes and raw materials, actual technical process optimization and a full-blown reporting structure that scientifically meausures success with live feedback from the market.
Visual and in-vitro inspections of all stages of production outputs from raw material to end product and identification of the root causes of surface quality issues in finished wood panels (MDF, HDF, etc.) Proven track record of quality improvement efforts enabling our clients to achieve differentiation through distinctive product quality in the market.
Coordination of R&D efforts between our clients and vendors aiming to create innovative, trendsetting products for the market. Exclusivity on conjointly developed products for our clients, creating long-lasting market leader opportunities.
Technical parameters
Capacity range | 50000~200000 | m3/a |
Board size | 4×16、4×18、6×18 | ft |
No. of daylight | 12-18 | Layer |
Board thickness | 8~25 | mm |
Board density | 600~880 | kg/m3 |
Technical parameters
Capacity range | 30000-120000 | 1. m3/a
|
Board size | 4×8, 6×8, 6×9 | 2. ft
|
No. of press daylight | 12-28 | 3. 层 Layer |
Board thickness range | 10-25 | 4. mm
|
Board density | 600-750 | 5. kg/m3
|
Technical parameters
Technical parameters Model | BSG2613M | BSG2613MG | BSG2613MGA | BSG2613MX | BSG2613MXX | BSG2713M | BSG2713MA | BSG2713MG | BSG2713MXX |
Number of sanding unit | 2 | 2 | 2 | 2 | 2 | 4 | 4 | 4 | 4 |
Maximum sanding width (mm) | 1300 | 1300 | 1300 | 1300 | 1300 | 1300 | 1300 | 1300 | 1300 |
Board thickness range (mm) | Mar-50 | Mar-50 | Mar-50 | Mar-50 | Mar-50 | Mar-50 | Mar-50 | Mar-50 | Mar-50 |
Sanding precision (reachable) | ±0.08 | ±0.08 | ±0.08 | ±0.08 | ±0.08 | ±0.08 | ±0.08 | ±0.08 | ±0.08 |
Feeding speed (reachable) | May-35 | May-35 | May-35 | May-35 | May-35 | May-35 | May-35 | May-35 | May-35 |
Size of sanding belt (L × W) | 2800×1350 | 2800×1350 | 2800×1350 | 2800×1350 | 3000×1400 | 2800×1350 | 2800×1350 | 2800×1350 | 2800×1350 |
Total motor power (kW) | 123.7 | 163.7 | 193.7 | 123.7 | 123.7 | 277.2 | 237.2 | 381.2 | 237.2 |
Main motor power (optional) kW | 2×55 | 2×75 | 2×90 | 2×55 | 2×55 | 2×75
2×55 |
4×55 | 4×90 | 4×55 |
Air volume of de-dusting blower | 22000 | 28000 | 28000 | 22000 | 22000 | 33000 | 33000 | 34500 | 33000 |
Compressed air pressure (Mpa) | 0.6 | 0.6 | 0.6 | 0.6 | 0.6 | O.6 | O.6 | O.6 | O.6 |
Compressed air consumption (Nm3/h) | ~5 | ~5 | ~5 | ~5 | ~5 | ~7 | ~7 | ~7 | ~7 |
mm | 2460×3400 | 2450×3530 | 2450×3530 | 2460×3400 | 2570×3400 | 3630×3500 | 3670×3400 | 3640×3530 | 3920×3400 |
Overall dimension (L × W × H) mm | ×2950 | ×2950 | ×3120 | ×2950 | ×2950 | ×2950 | ×2950 | ×3120 | ×2950 |
Weight kg | 16100 | 15000 | 18600 | 14900 | 15200 | 25850 |
Main technical parameters:
Capacity | 120,000-450,000m3/year |
Book height | 120-250mm |
Cutting accuracy | |
Diagonal tolerance | ≤2mm
|
Edge straightness | ≤1mm |
Width and length tolerance | ≤1.5mm
|
Minimum size of finished board | 600×600mm |
Main technical parameters:
Number of surface forming station | 2 |
Production capacity (bulk flakers) | 2×20 m3/h |
Number of core layer forming Station | 1 |
Production capacity (bulk flakers) | 50 m3/h |
Forming mat width | 1340 mm |
Forming mat thickness | 30~120 mm |
Mat structure | Classification |
Air consumption | 2×5000 m3/h |
Power installation | 45.41 kW |
Main technical parameters:
Capacity (bone dry) | 8500~11000 Kg/h |
Initial moisture content of flakers | 70~80% |
Final moisture content of flakers | ≤3% |
Heat consumption | 600~800×104 kcal/h |
Heating medium | Flue gas |
Drive motor (frequency control) | 30 kW |
Drum rotation speed | 3-11 r/min |
Blower power | 355 kW |
Rotary discharger for wet flakers | 5.5 kW |
Rotary discharger for dry flakers | 5.5 kW |
Rotary discharger for multi-cyclone | 2.2 kW |
The main technical parameters:
Rotor diameter | φ2740 mm |
Rotor speed | 2-8 r/min |
The initial moisture content of wood shavings | ﹤80% |
Final moisture content of shavings | ≤3% |
Production capacity (dry) | 1400~1800 kg/h |
Main motor power | 22 kW |
Preheating fan | 5.5 kW |
Exhaust fan | 11 kW |
Heat medium | Heat transfer oil mm |
Dimensions | 12600X3680X4300 mm |
Weight | 27000 kg |
Main technical parameters
Nominal pressure | 12500 KN |
Opening | 260 mm |
Platen size | 2750×1680×120 mm |
Operation height | 1400 mm |
Number of daylight | 22 |
Diameter × number of hydraulic cylinder | φ400×4 mm |
Pressure of hydraulic system | 25 MPa |
Heating medium | Thermal oil |
Thermal oil temperature | ≤180 ℃ |
Fast closing time | ≤10 s |
Power installation | About 220 Kw |
Technical parameters
Capacity | 1100000-8500000m2 |
Base board thickness | 8-32mm |
Base board size | (1220-2135)X(2440-2750)mm |
No. of laminated paper | 1-3Pcs |
Pressing cycle (minimum) | 33 (dwell time 20s)s |
Press opening time | ≤2.5s |
Press closing time | ≤1.8s |
Feeding precision | ≤±0.5mm |
Technical parameters
Parameters/model | BX566 | BX568 | BX5610 | BX5612
BX5612A |
BX5615 |
Diameter of ringmm | 600 | 800 | 1000 | 1200 | 1500 |
Main motor powerkw | 55 | 90 | 132 | 200 | 315 |
Capacitykg/h | 300-800 | 500-1000 | 800-1600 | 1400-2600 | 3000-5000 |
Weightkg | 1500 | 2050 | 2500 | 3500 | 6500 |
Overall dimensionmm | 1775×1500×2150 | 2120×1867×2035 | 2582×2200×2315 | 2700×2520×2785 | 2930×2830×3410 |
Technical parameters/model | BX116A | BX1710 | BX6110D | BX1112 | BX1112-1 |
Disc diameter (mm) | 630 | 950 | 950 | 1220 | 1220 |
Blade quantity (pieces) | 3 | 6 | 6 | 4 | 4 |
Chips length (mm) | 15-25 | 12-35 | 12-35 | 20-35 | 20-35 |
Feeding method | Horizontal | Tilt | Tilt | Horizontal | Horizontal |
Feeding opening(mm) | 130×150 | 207×190 | 207×190 | 400×275 | 400×275 |
Capacity (solid volume) (m3/h) | 2-3 | 5.5-8 | 5.5-8 | 15-20 | 15-20 |
Main motor power (kw) | 22 | 75 | 75 | 110 | 110 |
Maximum logs diameter (mm) | φ100 | φ100 | φ100 | φ200 | φ200 |
Discharge method | Up | Up | Up | Up | Down |
Machine weight kg | 827 | 2080 | 2406 | 4585 | 4256 |
Overall dimensions (mm) | 2340×1200
×1845 |
2550×1600
×1650 |
3983×2556
×1940 |
3000×1570
×1614 |
3000×1400×1614 |
Remarks | Optional diesel engine | Right feeding | Right feeding | Right feeding | Right feeding |
Technical parameters/model | BX1212 | BX1212A | BX1216 | BX1216-1 | BX1216-2 |
Disc diameter (mm) | 1220 | 1220 | 1600 | 1600 | 1600 |
Blade quantity (pieces) | 6 | 6 | 6 | 6 | 6 |
Chips length (mm) | 20-35 | 20-35 | 20-35 | 20-35 | 20-35 |
Feeding method | Tilt | Tilt | Horizontal | Horizontal | Horizontal |
Feeding opening(mm) | 300×300 | 300×300 | 545×383 | 545×383 | 545×383 |
Capacity (solid volume) (m3/h) | 15-20 | 15-20 | 25-45 | 25-45 | 25-45 |
Main motor power (kw) | 90 | 110 | 220-250 | 220 | 220-250 |
Maximum logs diameter (mm) | φ160 | φ200 | φ300 | φ300 | φ300 |
Discharge method | Up | Down | Up | Down | Up |
Machine weight kg | 4256 | 4585 | 8732 | 8433 | 8732 |
Overall dimensions (mm) | 3000×1400
×1614 |
3100×1340×
2093 |
3756×1855×
2093 |
3756×1855×
2020 |
3756×1855×
2093 |
Remarks | Re-chipping of wood chips | Right feeding | Right feeding | Right feeding | Left feeding |
Technical parameters/model | BX1216-3 | BX1216-4 | BX1220 | BX1520/8 | BX1225 | BX1227 |
Disc diameter (mm) | 1600 | 1600 | 2060 | 2330 | 2490 | 2650 |
Blade quantity (pieces) | 6 | 6 | 8 | 8 | 8 | 8 |
Chips length(mm) | 20-35 | 20-35 | 20-35 | 20-30 | 20-35 | 20-35 |
Feeding method | Horizontal | Tilt | Horizontal | Horizontal | Horizontal | Horizontal |
Feeding opening(mm) | 545×383 | 545×383 | 584×560 | 590×590 | 650×615 | 584×600 |
Capacity (solid volume)(m3/h) | 25-45 | 25-45 | 110 | 130 | 160 | 100-130 |
Main motor power (kw) | 220 | 220 | 500 | 160×4 | 315×2 | 2×280 |
Maximum logs diameter (mm) | φ300 | φ300 | φ500 | φ450 | φ450 | φ500 |
Discharge method | Down | Down | Down | Down | Down | Down |
Machine weight kg | 8732 | 8732 | 29140 | 17000 | 19000 | 32450 |
Overall dimensions (mm) | 3756×1855
×2093 |
3756×1855
×2093 |
6410×
3963× 3025 |
4400×3485
×5340 |
5845×2580
×3185 |
5745×4785
×2845 |
Remarks | Left feeding | Tilt feeding | Right feeding | Tilt cutter | Vertical cutter | Right feeding |
Main technical parameters:
Number of cooling grids: | 80 |
Maximum size of master board: | 2550 × 5600mm |
Drum re-chipper
Parameters/model | BX326 | BX328 | |
Drum diameter (mm) | 650 | 800 | |
Drum speed (rpm) | 590 | 836 | 650 |
Number of knives (pieces) | 2 | 2 | |
Capacity (m3/h) | 5-30 | 6-30 | |
Feeding opening (mm) | 300×600 | 892×350 | |
Chips length (mm) | 12-35 | 12-40 | |
Main motor power (kw) | 37-45 | 55 | |
Total weight (kg) | 2300 | 3540 | |
Raw material | Over-sized chips, short wood chips, etc. | ||
Feeding method | Upper feeding | ||
Hammer mill
Model/technical parameters | BX348 | BX348A | BX349 | BX3410 | BX3410/12 | BX3413 | BX3413/13 | BX4812 | BX3812/20 | |
Rotor diameter (mm) | 850 | 850 | 925 | 960 | 1000 | 1350 | 1300 | 1200 | 1200 | |
Rotor speed (rpm) | 1050 | 1050 | 1150 | 1480 | 1160 | 740 | 880 | 1250 | 1100 | |
Number of hammer (heads) | 696 | 372 | 3 | 28 | 28 | 696 | 32 | 198 | 342 | |
Capacity (kg/h) | 5000 | 2500 | 40 | 2000-3000 | 5000-10000 | 80m3/h | 50 m3/h | 3000 | 6000-8000 | |
Feeding opening (mm) | 2034×600 | 1213×600 | Φ940 | 300×900 | 350×1050 | 1052 ×900 |
902 ×900 |
400×1250 | 1220×430 | 420×2000 |
Main motor power (kw) | 75 | 55 | 45 | 160 | 160 | 132 | 250 | 200 | 250 | |
Total weight (kg) | 3425 | 2446 | 3500 | 12000 | 12000 | 7023 | 16000 | 6000 | 6300 | |
Overall dimension (mm) | 2034×600 ×1230 |
1784×1370 ×1230 |
2400×1400 ×1300 |
3980×2480 ×1900 |
2850×2799 ×1482 |
2874×2092 ×1692 |
3490×3060 ×1840 |
3246×3246 ×1885 |
2980×2000 ×1885 |
|
Raw materials | Flakers | Flakers | Bark | Logs, branches, veneer waste, wood stick etc. | Waste from furniture factory, urban waste | Cotton stalks | Waste from furniture factory, urban waste | Wood chips | Wood chips | |
Feeding method | Upper feeding | Upper feeding | Upper feeding | Horizontal forced feeding | Horizontal forced feeding | Upper feeding | Horizontal forced feeding | Upper feeding | Upper feeding |
Parameters/model | 100,000 m3/a (BP × 10) | 150,000 m3/a (BP × 15) | 200,000 m3/a (BP × 20) | 300,000 m3/a (BP × 30) | 400,000 m3/a (BP × 40) |
Chain conveyor (feeding) | BZY416/24 | BZY4110/28 | BZY4110/28 | BZY4110/28 | BZY4120/32 |
Conveying capacity: m³/h | 80 | 115 | 150 | 200 | 300 |
Feed chute of debarker | FB31 | BPX201 | BPX201 | BPX201 | BPX401 |
Chute Length: mm | 6460 | 5500 | 5500 | 5500 | 5500 |
Drum debarker | BBP1130/18 | BBP1140/15 | BBP1140/21 | BBP1140/27 | BBP1150/27 |
Capacity (m³/h) | 80 | 115 | 150 | 200 | 300 |
Chain conveyor (discharge) | BZY416/7 | BZY418/7 | BZY4110/7 | BZY4110/7 | BZY4112/13 |
Conveying capacity: m³/h | 70 | 105 | 140 | 185 | 280 |
Drum chipper | BX2113/13 | BX2113/13 | BX2116/13 | BX2116/13 | BX2120/13 |
Capacity (m³/h) | 132 | 132 | 185 | 185 | 280 |
Technical parameters
Parameters/model | BF1420A | BF1420E | BF14100 | BF14120 | BF14150 |
Number of screen layers | 3 (layers) | 3 (layers) | 3 (layers) | 3 (layers) | 3 (layers) |
Mesh size (upper layer) mm | Ф35Ф40Ф45 | 65×65 | 65×65 | 60×60 | 65×65 |
Mesh size (middle layer) mm | φ5 | φ4 | φ4 | φ4 | φ4 |
Screen area m2 | 2.65 | 8 | 10 | 12.5 | 15 |
Capacity (bulk) (m3/h) | 15 | 100-130 | 150-200 | 250-300 | 300-350 |
Motor power (kw) | 4 | 7.5 | 11 | 11 | 15 |
Overall dimension (L×W×H) mm | 2700×1560×1580 | 5250×2670×1880 | 5650×3210×2250 | 6710×3240×2650 | 6500×3950×2600 |
Weight kg | 1800 | 3500 | 3750 | 6250 | 7000 |
Parameters/model | BX216 | BX218 | BX218-1 | BX218D | BX218E | BX2110 | BX2113 | BX2113A | BX2113/11 | BX2113/13 | BX2116 | BX2120 | |||
Drum diametermm | 650 | 800 | 800 | 800 | 800 | 1000 | 1300 | 1300 | 1300 | 1300 | 1600 | 2000 | |||
Number of knives (pieces) | 2 | 2 | 2 | 2 | 2×4 | 2×2 | 2 | 3 | 4 | 3×2 | 4×2 | 4×2 | 3×2 | ||
Feeding opening size | 180×500 | 225×680 | 225×680 | 240×750 | 200×750 | 330×1050 | 400×700 | 400×700 | 400×1050 | 400×1250 | 600×1250 | 850×1250 | |||
Maximum diameter of logsmm | 120 | 160 | 160 | 160 | 160 | 210 | 230 | 230 | 230 | 250 | 310 | 370 | |||
Length of chipsmm | 30 | 22 | 30 | 20 | 30 | 30 | 30 | 30 | 38 | 30 | 25 | 30 | 30 | 30 | 35 |
Capacitym3/h | 10 | 15-20 | 15-20 | 38 | 15-18 | 75 | 34-64 | 34 | 60-70 | 100 | 132 | 185 | 190 | ||
Main motor powerkw | 55 | 110 | 110 | 132 | 132 | 220 | 200-250 | 200-250 | 250 | 315 | 450 | 710 | 1000 | ||
Weightkg | 4070 | 7000 | 7500 | 7300 | 7300 | 12500 | 11800 | 11800 | 14500 | 20540 | 32000 | 55000 | |||
Overall dimension(L×W×H) | 4348 ×1730 ×1258 |
4670 ×2150 ×1500 |
4920 ×2500 ×1500 |
4670 ×2150 ×1500 |
4670 ×2150 ×1500 |
4340 ×3550 ×1500 |
3670 ×2517 ×2050 |
3670 ×2517 ×2050 |
3485 ×2860 ×1830 |
5484 ×2860 ×1830 |
4360 ×3150 ×2200 |
7970 ×7150 ×2750 |
Parameters/model | BM1111/15/15 | BM1111/15/15M | BM1111/15/23 | BM1112/15/33 | BM1114/15/45 | BM1115/15/58 | ||
Productivity | Suitable for MDF production line (m3/yr) | 30000~50000 | >50000 | 80000 | 100000 | 150000 | 200000 | |
Bone dry fiber | Average daily Capacity (t) | 120~150 | >150 | 230 | 330 | 450 | 580 | |
Average Capacity per hour (t) | ≈7 | >7 | ≈10 | ≈13 | ≈20 | ≈26 | ||
Main motor power | 1120~1400 | 1600 | 2240 | 3000 | 4000~4500 | 4500~5600 | ||
Segment size | 42 | 42~44 | 44 | 45~49 | 50~54 | 55~58 | ||
Sealing method of refining chamber | Mechanical sealing | Mechanical sealing | Mechanical sealing | Mechanical sealing | Mechanical sealing | Mechanical sealing | ||
Overall weight | ≈35000 | ≈42000 | ≈45000 | ≈57000 | ≈75000 | ≈80000 |
Parameters/model | BM1111/15/15 | BM1111/15/15M | BM1111/15/23 | BM1112/15/33 | BM1114/15/45 | BM1115/15/58 | ||
Capacity | Machine for MDF production line (m3/yr) | 30000~50000 | >50000 | 80000 | 100000 | 150000 | 200000 | |
Bone dry fiber | Average daily capacity (t) | 120~150 | >150 | 230 | 330 | 450 | 580 | |
Average Capacity per hour (t) | ≈7 | >7 | ≈10 | ≈13 | ≈20 | ≈26 | ||
Main motor power | 1120~1400 | 1600 | 2240 | 3000 | 4000~4500 | 4500~5600 | ||
Specification of segment | 42 | 42~44 | 44 | 45~49 | 50~54 | 55~58 | ||
Sealing of refining housing | Mechanical sealing | Mechanical sealing | Mechanical sealing | Mechanical sealing | Mechanical sealing | Mechanical sealing | ||
Overall weight | ≈35000 | ≈42000 | ≈45000 | ≈57000 | ≈75000 | ≈80000 |
Technical parameters
Parameters/model | BX466 | BX468 | BX4612 | BX4612/5 | BX4614/5 |
Ring diameter (mm) | 600 | 800 | 1200 | 1200 | 1400 |
Thickness of flakers (mm) | 0.4-0.7 | 0.4-0.7 | 0.4-0.7 | 0.3-0.8 | 0.6-1.2 |
Main motor power (kw) | 75 | 132 | 200 | 250 | 315 |
Capacity (kg/h) | 700-900 | 1500-3000 | 2500-4000 | 5000-8000 | 8000-11000 |
Weight kg | 3500 | 5800 | 8500 | 9000 | 9600 |
Overall dimension (mm) | 2800×2265×2110 | 3130×2512×2380 | 3443×2753×2840 | 3615×2595×3000 | 4200×3200×2930 |
