CT1300

Datasheet_CT1300

DT1320

Datasheet_DT1320

MT1500

Datasheet_MT1500

MT1650

Datasheet_MT1650

MDFHDF presses

技术参数
Technical parameters

产能范围
Capacity range
50000~200000 m3/a
生产幅面
Board size
4×16、4×18、6×18 ft
压机层数
No. of daylight
12-18 层
Layer
成品板厚度范围
Board thickness
8~25 mm
产品容重
Board density
600~880 kg/m3
Particle Board Production Lines

技术参数
Technical parameters

产能范围
Capacity range
30000-120000 1.     m3/a



幅面规格
Board size
4×8, 6×8, 6×9 2.     ft



压机层数
No. of press daylight
12-28 3.     层
Layer
成品板厚度范围
Board thickness range
10-25 4.     mm



产品容重
Board density
600-750 5.     kg/m3



Sanding Lines

技术参数
Technical parameters

技术参数 型号

Technical parameters      Model

BSG2613M BSG2613MG BSG2613MGA BSG2613MX BSG2613MXX BSG2713M BSG2713MA BSG2713MG BSG2713MXX
砂架数量

Number of sanding unit

2 2 2 2 2 4 4 4 4
最大加工宽度mm

Maximum sanding width (mm)

1300 1300 1300 1300 1300 1300 1300 1300 1300
工件厚度范围mm Board thickness range (mm) Mar-50 Mar-50 Mar-50 Mar-50 Mar-50 Mar-50 Mar-50 Mar-50 Mar-50
加工精度(可达)

Sanding precision (reachable)

±0.08 ±0.08 ±0.08 ±0.08 ±0.08 ±0.08 ±0.08 ±0.08 ±0.08
进料速度(可达) Feeding speed (reachable) May-35 May-35 May-35 May-35 May-35 May-35 May-35 May-35 May-35
砂带尺寸(长×宽)

Size of sanding belt (L × W)

2800×1350 2800×1350 2800×1350 2800×1350 3000×1400 2800×1350 2800×1350 2800×1350 2800×1350
电机总功率kW

Total motor power (kW)

123.7 163.7 193.7 123.7 123.7 277.2 237.2 381.2 237.2
砂架主电机功率(可选)kW

Main motor power (optional) kW

2×55 2×75 2×90 2×55 2×55 2×75

2×55

4×55 4×90 4×55
吸层风量

Air volume of de-dusting blower

22000 28000 28000 22000 22000 33000 33000 34500 33000
压缩空气压力Mpa

Compressed air pressure (Mpa)

0.6 0.6 0.6 0.6 0.6 O.6 O.6 O.6 O.6
压缩空气耗量Nm3/h

Compressed air consumption (Nm3/h)

~5 ~5 ~5 ~5 ~5 ~7 ~7 ~7 ~7
外形尺寸(长×宽×高)mm 2460×3400 2450×3530 2450×3530 2460×3400 2570×3400 3630×3500 3670×3400 3640×3530 3920×3400
Overall dimension (L × W × H) mm ×2950 ×2950 ×3120 ×2950 ×2950 ×2950 ×2950 ×3120 ×2950
重量kg Weight kg 16100 15000 18600 14900 15200 25850
Cut-to-Size (CTS) Lines

主要技术参数:
Main technical parameters:

生产能力
Capacity
12-45万m3/年
120,000-450,000m3/year
锯切高度
Book height
120-250mm
锯切精度
Cutting accuracy
对角线误差
Diagonal tolerance
≤2mm



板边直线度误差
Edge straightness
≤1mm
板的宽度和长度误差
Width and length tolerance
≤1.5mm



最小成品板的规格
Minimum size of finished board
600×600mm
Defibrator
参数/型号
Parameters/model
BM1111/15/15 BM1111/15/15M BM1111/15/23 BM1112/15/33 BM1114/15/45 BM1115/15/58
产能
Capacity
适用于MDF生产线(m3/yr)
Machine for MDF production line (m3/yr)
30000~50000 >50000 80000 100000 150000 200000
绝干纤维
Bone dry fiber
平均每天产量(t)
Average daily capacity (t)
120~150 >150 230 330 450 580
平均每小时产量(t)
Average Capacity  per hour (t)
≈7 >7 ≈10 ≈13 ≈20 ≈26
主电机功率
Main motor power
1120~1400 1600 2240 3000 4000~4500 4500~5600
磨片规格
Specification of segment
42 42~44 44 45~49 50~54 55~58
磨室体密封方式
Sealing of refining housing
机械密封
Mechanical sealing
机械密封
Mechanical sealing
机械密封
Mechanical sealing
机械密封
Mechanical sealing
机械密封
Mechanical sealing
机械密封
Mechanical sealing
整体重量
Overall weight
≈35000 ≈42000 ≈45000 ≈57000 ≈75000 ≈80000
Hot Presses

主要技术参数:
Main technical parameters:

公称压力
Nominal pressure
12500  KN
层间距
Opening
260  mm
压板尺寸
Platen size
2750×1680×120   mm
工作面标高
Operation height
1400 mm
层数
Number of daylight
22
压力缸直径×数量
Diameter × number of hydraulic cylinder
φ400×4 mm
液压系统压力
Pressure of hydraulic system
25 MPa
加热介质
Heating medium
导热油
Thermal oil
加热温度
Thermal oil temperature
≤180 ℃
快速闭合时间
Fast closing time
≤10 s
总装机容量
Power installation
约220 Kw
About 220 Kw
Debarker
参数/型号
Parameters/model
10万m3/a(BP×10)
100,000 m3/a (BP × 10)
15万m3/a(BP×15)
150,000 m3/a (BP × 15)
20万m3/a(BP×20)
200,000 m3/a (BP × 20)
30万m3/a(BP×30)
300,000 m3/a (BP × 30)
40万m3/a(BP×40)
400,000 m3/a (BP × 40)
链式运输机(上料)
Chain conveyor (feeding)
BZY416/24 BZY4110/28 BZY4110/28 BZY4110/28 BZY4120/32
运输能力:m³/h
Conveying capacity: m³/h
80 115 150 200 300
剥皮机进料斜槽
Feed chute of debarker
FB31 BPX201 BPX201 BPX201 BPX401
斜槽长度:mm
Chute Length: mm
6460 5500 5500 5500 5500
滚筒式剥皮机
Drum debarker
BBP1130/18 BBP1140/15 BBP1140/21 BBP1140/27 BBP1150/27
生产能力:m³/h
Capacity (m³/h)
80 115 150 200 300
链式运输机(出料)
Chain conveyor (discharge)
BZY416/7 BZY418/7 BZY4110/7 BZY4110/7 BZY4112/13
输送能力:m³/h
Conveying capacity: m³/h
70 105 140 185 280
鼓式削片机
Drum chipper
BX2113/13 BX2113/13 BX2116/13 BX2116/13 BX2120/13
生产能力:m³/h
Capacity (m³/h)
132 132 185 185 280
Three-pass Dryers

主要技术参数:
Main technical parameters:

生产能力(绝干)
Capacity (bone dry)
8500~11000 Kg/h
刨花初含水率
Initial moisture content of flakers
70~80%
刨花终含水率
Final moisture content of flakers
≤3%
热量消耗
Heat consumption
600~800×104 kcal/h
热介质
Heating medium
烟道气
Flue gas
驱动电机(变频调速)
Drive motor (frequency control)
30 kW
辊筒转速
Drum rotation speed
3-11 r/min
风机功率
Blower power
355 kW
湿刨花回转下料器
Rotary discharger for wet flakers
5.5 kW
干刨花回转下料器
Rotary discharger for dry flakers
5.5 kW
除尘器回转下料器
Rotary discharger for multi-cyclone
2.2 kW
Forming Machines

主要技术参数:
Main technical parameters:

表层铺装机台数
Number of surface forming station
2
生产能力(松散刨花)
Production capacity (bulk flakers)
2×20 m3/h
芯层铺装机台数
Number of core layer forming Station
1
生产能力(松散刨花)
Production capacity (bulk flakers)
50 m3/h
铺装宽度
Forming mat width
1340 mm
铺装厚度
Forming mat thickness
30~120 mm
板坯结构
Mat structure
渐变
Classification
耗气量
Air consumption
2×5000 m3/h
装机容量
Power installation
45.41 kW
Knife Ring Flakers

技术参数
Technical parameters

参数/型号
Parameters/model
BX466 BX468 BX4612 BX4612/5 BX4614/5
刀环直径 mm
Ring diameter (mm)
600 800 1200 1200 1400
刨花厚度 mm
Thickness of flakers (mm)
0.4-0.7 0.4-0.7 0.4-0.7 0.3-0.8 0.6-1.2
主电机功率 kw
Main motor power (kw)
75 132 200 250 315
生产能力 kg/h
Capacity (kg/h)
700-900 1500-3000 2500-4000 5000-8000 8000-11000
重量 kg
Weight kg
3500 5800 8500 9000 9600
外型尺寸 mm
Overall dimension (mm)
2800×2265×2110 3130×2512×2380 3443×2753×2840 3615×2595×3000 4200×3200×2930
Rotor Dryers

主要技术参数:

转子直径 φ2740 mm
转子转速 2-8     r/min
刨花初含水率 ﹤80%
刨花终含水率 ≤3%
生产能力(绝干) 1400~1800  kg/h
主电机功率 22      kW
预热风机 5.5     kW
排湿风机 11      kW
热介质 导热油 mm
外形尺寸 12600X3680X4300  mm
重量 27000 kg
Disc Chipper
技术参数/型号
Technical parameters/model
BX116A BX1710 BX6110D BX1112 BX1112-1
刀盘直径(mm)
Disc diameter (mm)
630 950 950 1220 1220
刀片数量(片)
Blade quantity (pieces)
3 6 6 4 4
木片长度范围(mm)
Chips length (mm)
15-25 12-35 12-35 20-35 20-35
喂料方式
Feeding method
水平
Horizontal
倾斜
Tilt
倾斜
Tilt
水平
Horizontal
水平
Horizontal
喂料口尺寸(mm)
Feeding opening(mm)
130×150 207×190 207×190 400×275 400×275
生产能力(实积)(m3/h)
Capacity (solid volume) (m3/h)
2-3 5.5-8 5.5-8 15-20 15-20
主电机功率(kw)
Main motor power (kw)
22 75 75 110 110
切削原木最大直径(mm)
Maximum logs diameter (mm)
φ100 φ100 φ100 φ200 φ200
出料方式
Discharge method
上
Up
上
Up
上
Up
上
Up
下
Down
整机重量(kg)
Machine weight kg
827 2080 2406 4585 4256
外型尺寸(mm)
Overall dimensions (mm)
2340×1200

×1845

2550×1600

×1650

3983×2556

×1940

3000×1570

×1614

3000×1400×1614
备注
Remarks
可配柴油机
Optional diesel engine
右进料
Right feeding
右进料
Right feeding
右进料
Right feeding
右进料
Right feeding



技术参数/型号
Technical parameters/model
BX1212 BX1212A BX1216 BX1216-1 BX1216-2
刀盘直径(mm)
Disc diameter (mm)
1220 1220 1600 1600 1600
刀片数量(片)
Blade quantity (pieces)
6 6 6 6 6
木片长度范围(mm)
Chips length (mm)
20-35 20-35 20-35 20-35 20-35
喂料方式
Feeding method
倾斜
Tilt
倾斜
Tilt
水平
Horizontal
水平
Horizontal
水平
Horizontal
喂料口尺寸(mm)
Feeding opening(mm)
300×300 300×300 545×383 545×383 545×383
生产能力(实积)(m3/h)
Capacity (solid volume) (m3/h)
15-20 15-20 25-45 25-45 25-45
主电机功率(kw)
Main motor power (kw)
90 110 220-250 220 220-250
切削原木最大直径(mm)
Maximum logs diameter (mm)
φ160 φ200 φ300 φ300 φ300
出料方式
Discharge method
上
Up
下
Down
上
Up
下
Down
上
Up
整机重量(kg)
Machine weight kg
4256 4585 8732 8433 8732
外型尺寸(mm)
Overall dimensions (mm)
3000×1400

×1614

3100×1340×

2093

3756×1855×

2093

3756×1855×

2020

3756×1855×

2093

备注
Remarks
木片再碎
Re-chipping of wood chips
右进料
Right feeding
右进料
Right feeding
右进料
Right feeding
左进料
Left feeding



技术参数/型号
Technical parameters/model
BX1216-3 BX1216-4 BX1220 BX1520/8 BX1225 BX1227
刀盘直径(mm)
Disc diameter (mm)
1600 1600 2060 2330 2490 2650
刀片数量(片)
Blade quantity (pieces)
6 6 8 8 8 8
木片长度范围
chips length(mm)
20-35 20-35 20-35 20-30 20-35 20-35
喂料方式
Feeding method
水平
Horizontal
倾斜
Tilt
水平
Horizontal
水平
Horizontal
水平
Horizontal
水平
Horizontal
喂料口尺寸(mm)
Feeding opening(mm)
545×383 545×383 584×560 590×590 650×615 584×600
生产能力(实积)
Capacity (solid volume)(m3/h)
25-45 25-45 110 130 160 100-130
主电机功率(kw)
Main motor power (kw)
220 220 500 160×4 315×2 2×280
切削原木最大直径(mm)
Maximum logs diameter (mm)
φ300 φ300 φ500 φ450 φ450 φ500
出料方式
Discharge method
下
Down
下
Down
下
Down
下
Down
下
Down
下
Down
整机重量(kg)
Machine weight kg
8732 8732 29140 17000 19000 32450
外型尺寸 (mm)
Overall dimensions (mm)
3756×1855

×2093

3756×1855

×2093

6410×

3963×

3025

4400×3485

×5340

5845×2580

×3185

5745×4785

×2845

备注
Remarks
左进料
Left feeding
倾斜进料
Tilt feeding
右进料
Right feeding
倾斜刀盘
Tilt cutter
垂直刀盘
Vertical cutter
右进料
Right feeding
Star Cooler

主要技术参数:
Main technical parameters:

冷却栅数量:

Number of cooling grids:

80
最大毛板规格:

Maximum size of master board:

2550 × 5600mm
Re-Chipper

鼓式再碎机
Drum re-chipper

参数/型号
Parameters/model
BX326 BX328
刀辊直径mm
Drum diameter (mm)
650 800
刀辊转速rpm
Drum speed (rpm)
590 836 650
飞刀数(把)
Number of knives (pieces)
2 2
生产能力m3/h
Capacity (m3/h)
5-30 6-30
进口碎料尺寸mm
Feeding opening (mm)
300×600 892×350
再碎后木片长度mm
Chips length (mm)
12-35 12-40
主电机功率kw
Main motor power (kw)
37-45 55
总重kg
Total weight (kg)
2300 3540
切削原料
Raw material
过大木片、木材短料、截头等
Over-sized chips, short wood chips, etc.
进料方式
Feeding method
上进料
Upper feeding



锤式再碎机
Hammer mill

型号/技术参数
Model/technical parameters
BX348 BX348A BX349 BX3410 BX3410/12 BX3413 BX3413/13 BX4812 BX3812/20
转子直径mm
Rotor diameter (mm)
850 850 925 960 1000 1350 1300 1200 1200
转子转速rpm
Rotor speed (rpm)
1050 1050 1150 1480 1160 740 880 1250 1100
锤片数(头)
Number of hammer (heads)
696 372 3 28 28 696 32 198 342
生产能力kg/h
Capacity (kg/h)
5000 2500 40 2000-3000 5000-10000 80m3/h 50 m3/h   3000 6000-8000
喂料口尺寸mm
Feeding opening (mm)
2034×600 1213×600 Φ940 300×900 350×1050 1052
×900
902
×900
400×1250 1220×430 420×2000
主电机功率kw
Main motor power (kw)
75 55 45 160 160 132 250 200 250
总重kg
Total weight (kg)
3425 2446 3500 12000 12000 7023 16000 6000 6300
外形尺寸mm
Overall dimension (mm)
2034×600
×1230
1784×1370
×1230
2400×1400
×1300
3980×2480
×1900
2850×2799
×1482
2874×2092
×1692
3490×3060
×1840
3246×3246
×1885
2980×2000
×1885
切削原料
Raw materials
刨花
Flakers
刨花
Flakers
树皮
Bark
枝丫材、原木、小径木、板皮、板条等
Logs, branches, veneer waste, wood stick etc.
短料头、板皮、板条、家具厂下脚料、破碎后的城市废料
Waste from furniture factory, urban waste
棉杆
Cotton stalks
短料头、板皮、板条、家具厂下脚料、破碎后的城市废料
Waste from furniture factory, urban waste
木片
Wood chips
木片
Wood chips
进料方式
Feeding method
上进料
Upper feeding
上进料
Upper feeding
上进料
Upper feeding
水平强制进料
Horizontal forced feeding
水平强制进料
Horizontal forced feeding
上进料
Upper feeding
水平强制进料
Horizontal forced feeding
上进料
Upper feeding
上进料
Upper feeding
Screen

技术参数
Technical parameters

参数/型号
Parameters/model
BF1420A BF1420E BF14100 BF14120 BF14150
筛选层数
Number of screen layers
3(层)
3 (layers)
3(层)
3 (layers)
3(层)
3 (layers)
3(层)
3 (layers)
3(层)
3 (layers)
筛孔尺寸(上层)mm
Mesh size (upper layer) mm
Ф35Ф40Ф45 65×65 65×65 60×60 65×65
筛孔尺寸(中层)mm
Mesh size (middle layer) mm
φ5 φ4 φ4 φ4 φ4
筛选面积m2
Screen area m2
2.65 8 10 12.5 15
生产能力(木片堆积)m3/h
Capacity (bulk) (m3/h)
15 100-130 150-200 250-300 300-350
电机功率kw
Motor power (kw)
4 7.5 11 11 15
外形尺寸(L×W×H)mm
Overall dimension (L×W×H) mm
2700×1560×1580 5250×2670×1880 5650×3210×2250 6710×3240×2650 6500×3950×2600
重量kg
Weight kg
1800 3500 3750 6250 7000
Drum Chipper
参数/型号
Parameters/model
BX216 BX218 BX218-1 BX218D BX218E BX2110 BX2113 BX2113A BX2113/11 BX2113/13 BX2116 BX2120
刀辊直径
Drum diameter

mm

650 800 800 800 800 1000 1300 1300 1300 1300 1600 2000
飞刀数(把)
Number of knives (pieces)
2 2 2 2 2×4 2×2 2 3 4 3×2 4×2 4×2 3×2
进料口尺寸
Feeding opening size
180×500 225×680 225×680 240×750 200×750 330×1050 400×700 400×700 400×1050 400×1250 600×1250 850×1250
加工原料最大直径
Maximum diameter of logs

mm

120 160 160 160 160 210 230 230 230 250 310 370
木片长度
Length of chips

mm

30 22 30 20 30 30 30 30 38 30 25 30 30 30 35
生产能力
Capacity

m3/h

10 15-20 15-20 38 15-18 75 34-64 34 60-70 100 132 185 190
主电机功率
Main motor power

kw

55 110 110 132 132 220 200-250 200-250 250 315 450 710 1000
重量
Weight

kg

4070 7000 7500 7300 7300 12500 11800 11800 14500 20540 32000 55000
外型尺寸
Overall dimension

(L×W×H)

4348
×1730
×1258
4670
×2150
×1500
4920
×2500
×1500
4670
×2150
×1500
4670
×2150
×1500
4340
×3550
×1500
3670
×2517
×2050
3670
×2517
×2050
3485
×2860
×1830
5484
×2860
×1830
4360
×3150
×2200
7970
×7150
×2750
Base Board Line

技术参数
Technical parameters

年产量
Capacity
110-850 万m2
1100000-8500000m2
贴面板厚度
Base board thickness
8-32mm
贴面板幅面
Base board size
(1220-2135)X(2440-2750)mm
一次贴面板张数
No. of laminated paper
1-3张
1-3Pcs
热压周期(最短)
Pressing cycle (minimum)
33(保压时间20s)s
33 (dwell time 20s)s
压机打开时间
Press opening time
≤2.5s
压机闭合时间
Press closing time
≤1.8s
跑车往复精度
Feeding precision
≤±0.5mm
Refiner
参数/型号
Parameters/model
BM1111/15/15 BM1111/15/15M BM1111/15/23 BM1112/15/33 BM1114/15/45 BM1115/15/58
产能
Productivity
适用于MDF生产线(m3/yr)
Suitable for MDF production line (m3/yr)
30000~50000 >50000 80000 100000 150000 200000
绝干纤维
Bone dry fiber
平均每天产量(t)
Average daily Capacity (t)
120~150 >150 230 330 450 580
平均每小时产量(t)
Average Capacity  per hour (t)
≈7 >7 ≈10 ≈13 ≈20 ≈26
主电机功率
Main motor power
1120~1400 1600 2240 3000 4000~4500 4500~5600
磨片规格
Segment size
42 42~44 44 45~49 50~54 55~58
磨室体密封方式
Sealing method of refining chamber
机械密封
Mechanical sealing
机械密封
Mechanical sealing
机械密封
Mechanical sealing
机械密封
Mechanical sealing
机械密封
Mechanical sealing
机械密封
Mechanical sealing
整体重量
Overall weight
≈35000 ≈42000 ≈45000 ≈57000 ≈75000 ≈80000
Mill Machine

技术参数
Technical parameters

参数/型号
Parameters/model
BX566 BX568 BX5610 BX5612

BX5612A

BX5615
磨筛环直径
Diameter of ringmm
600 800 1000 1200 1500
主电机功率
Main motor powerkw
55 90 132 200 315
生产能力
Capacitykg/h
300-800 500-1000 800-1600 1400-2600 3000-5000
重量
Weightkg
1500 2050 2500 3500 6500
外形尺寸
Overall dimensionmm
1775×1500×2150 2120×1867×2035 2582×2200×2315 2700×2520×2785 2930×2830×3410
